Acid Resistant Metal-Free Boron Carbide Sandblast Nozzle with Long Venturi 45x8mm for Ceramic Surface Treatment
Dettagli:
| Luogo di origine: | Hunan, Cina |
| Marca: | High Broad |
| Certificazione: | ISO 9001:2015 |
| Numero di modello: | HB-B4C |
| Documento: | Venturi nozzle Jane.pdf |
Termini di pagamento e spedizione:
| Quantità di ordine minimo: | 10 pezzi |
|---|---|
| Prezzo: | USD 10.00 - 28.00 / Piece |
| Imballaggi particolari: | Scatola individuale rivestita in schiuma, cartone ondulato per esportazione con barriera contro l |
| Tempi di consegna: | 3-5 giorni lavorativi per stock, 15-20 giorni per produzione |
| Termini di pagamento: | T/T,L/C,PayPal,Western Union |
| Capacità di alimentazione: | 50000 pezzi al mese |
|
Informazioni dettagliate |
|||
| Tipo di ugello: | Foro Venturi lungo | Discussione di connessione: | M16x1,5 |
|---|---|---|---|
| Diametro del foro: | 8 mm | Lunghezza dell'ugello: | 45 mm |
| Durezza: | ≥2800 Knoop (HK) | Pressione operativa massima: | 0,8 MPa (116 PSI) |
| Evidenziare: | Acid Alkali Resistant Nozzle,Zero Metal Contamination Design,Pure Ceramic Sandblast Tip |
||
Descrizione di prodotto
Key Advantages
Zero Metal Contamination
100% B4C ceramic body with no metallic components. Eliminates ferrous and non-ferrous contamination during blasting — critical for semiconductor, medical device, and aerospace component processing.
Acid and Alkali Resistant
Outstanding chemical inertness against acidic and alkaline environments. Performs reliably in wet blasting with chemical additives without material degradation.
Long Venturi Design
45mm extended venturi bore with 8mm diameter maximizes particle acceleration distance. Delivers superior blasting uniformity across large surface areas.
Ceramic Surface Ready
Optimized for ceramic, glass, quartz, and other brittle material surface treatments. Gentle yet effective abrasive flow preserves substrate integrity.
Technical Specifications
| Material | Boron Carbide (B4C) Ceramic |
| Nozzle Type | Long Venturi Bore |
| Bore Diameter | 8mm |
| Nozzle Length | 45mm |
| Metal Content | Zero (100% ceramic) |
| Chemical Resistance | Excellent acid/alkali resistance |
| Hardness | ≥2800 HK (Knoop) |
| Max Operating Pressure | 0.8 MPa (116 PSI) |
Applications
- Semiconductor wafer and component surface treatment
- Medical implant and surgical instrument finishing
- Ceramic and glass substrate etching and texturing
- Aerospace turbine blade coating preparation
- Precision optical component cleaning
